Gigabyte M27Q-EK

M27Q-EK Gaming Monitor

Gaming Features

OSD Sidekick

GameAssist

Counter - The gaming counter will help you calculate the time more easily.

Alignment - The display alignment function will facilitate you on the multi-display set-up, monitors will line up perfectly.

Crosshair - This feature will allow you to customize crosshairs that helps improve your aim in the shooting game.

Aim Stabilizer - This feature will reduce motion blur so you will have a better visual clarity that helps tracing the track of bullet and aim the target easily.

PIP /RBP - The PIP and PBP functions allow users to view different video sources which are presented in one screen at the same time, you are able to watch the game guides at the same time using only one monitor!

Timer - Onscreen timer will assist you on tracking the elapsed game time.

Dashboard

Black Equalizer

Auto-Update

Tech Features

Low Blue Light - Certified by TÜV Rheinland for eye health protection.

Flicker-Free - Preventing eye strain and fatigue.

Monitor Review

What is KVM?

TECHNICAL SPECIFICATIONS

Panel Size (diagonal) 27" SS IPS

Display Viewing Area (H x V) 596.736 x 335.663 mm

Panel Backlight/ Type

Edge type

Display Surface (non-glare/glare)

Non-glare

Color Saturation 92% DCI-P3 / 140% sRGB

True Resolution 2560 x 1440 (QHD)

Pixel Pitch (H x V) 0.2331 x 0.2331 mm

Brightness 350 cd/m2 (TYP)

Contrast Ratio 1000:1

Dynamic Contrast Ratio 100M:1

Viewing Angle (H / V) 178° / 178°

Display Colors 8 bits

Response Time 0.5 ms (MPRT)

Refresh Rate 170 Hz

HDR

VESA Display HDR400

Flicker-free

Yes

Signal Input

HDMI 2.0 x2, Display port 1.2 x1

Earphone Jack

Yes

Unique Features

OSD SidekickAim StabilizerBlack EqualizerDashboardCrosshairTimerCounterCrosshairPiP/PbPAuto-UpdateKVM

USB ports

USB 3.0 x2USB C x1

Power Type

Power adapter

Power Consumption 58 W (Max)

Power Saving Mode 0.5 W

Power Off Mode 0.3 W

Voltage 19 VDC 3.42 A

Tilt (angle) -5° - +20°

Swivel (angle)

N/A

Pivot (angle/direction)

N/A

Height Adjusment (mm) 130 mm

VESA Wall Mounting (mm) 100 x 100 m

Kensington lock

Yes

Phys. Dimension with Stand (W x H x D) 615.11 x 533.55 x 202.97

Phys. Dimension w/o stand (WxHxD) 615.11 x 367.35 x 42.22

Box Dimension (WxHxD) 720 x 470 x 200

Net Weight (Esti.) 5.5

Gross Weight (Esti.) 7.79

Accessories

Power cable/HDMI cable/DP cable/ USB cable/QSG/Warranty card
